2.890.000 đ
Siemens 7MF1565-3CA00-1AA1 - Transducer SITRANS P200 for pressure- Cảm biến áp suất 0-10 bar
Hàng có sẵn ATZ # : SIE-276
SITRANS P200 Transmitters for pressure and absolute pressure for general applications Non-linearity: 0,25 percent (typically) wetted parts material:ceramics, stainless steel plus sealing material; non-wetted parts material: stainless steel
Measuring range for gauge: 0 to 10 bar, Overload- pressure 25 bar
Output signal: 4 to 20 mA two-wire connection, power supply DC 7 to 33 V
without explosion protection
Electrical connection: plug to DIN EN 175301-803-A, threat for packed gland M16 (with connector)
Process connection: G1/2" male to EN 837-1 (1/2" BSP male) (standard for metric pressure ranges mbar, bar)
Sealing material between sensor and housing: Viton (FPM, Standard)
Standard version
